ABB catalog image for this SKU; may represent the product family.
HOLDER FOR CYLINDRICAL FUSE
E 91HN/20
SKU 2CSM200963R1801ABB E 91HN/20: Holder for cylindrical fuse. Pole configuration: 2P.
2PPoles
EProduct range
Holder for cylindrical fuseProduct type
PRODUCT DATA
Technical specifications
Source: ABB English regional product catalog.
Verified September 08, 2026.
| Product ID | 2CSM200963R1801 |
|---|---|
| Catalog Description | E 91HN/20 Fuse holder |
| Number of Protected Poles | 1 |
| Number of Poles | 2P |
| Position of Neutral Terminals | Right |
| Tightening Torque | 0.8...1.2 N·m |
| Fuse Type | gG and aM cylindrical fuse links |
| Lock Type | Padlockable |
| Sealing Type | Sealing Wire |
| Material of Conductor | Copper |
| Options Provided | No |
| Recommended Screw Driver | Pozidriv 2 |
| Shock and Vibration Withstand acc. to IEC 61373 | Category 1, Class B |
| Connecting Capacity | Stranded 1.5…10 mm² Rigid 1.5…16 mm² |
| Fuse Size | 8.5x31.5 mm |
| Operating Humidity (RHamb) | Maximum at +20 °C 90 % Maximum at +40 °C 50 % |
| Rated Operational Current AC (Ie) | 20 A |
| Fuse System | Cylindrical |
| Rated Voltage (Ur) | acc. To IEC 400 V |
| Rated Operational Voltage | 690 V AC |
| Rated Insulation Voltage (Ui) | 1 kV |
| Rated Frequency (f) | 50/60 Hz |
| Power Loss | Total 6 W at Rated Operating Conditions per Pole 3 W |
| RoHS Declaration | 2CSC444001D2701 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| RoHS Date | 20140101 |
| REACH Declaration | 9AKK108467A9482 |
| REACH Information | True - contains substances > 0.1 mass percentage |
| REACH Date | 20240429 |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108468A3363 |
| Ambient Air Temperature | Operation -5...+40 °C Storage -25...+70 °C |
| Degree of Protection | IP20 |
| Maximum Operating Altitude Permissible | 2000 m |
| Resistance to Vibrations | 1 mm 2 … 13 Hz |
| Resistance to Shock acc. to IEC 60068-2-27 | 15g 18 shocks 11 ms |
| Environmental Information | See RoHS Information |
| Width in Number of Modular Spacings | 1 |
| Product Net Width | 18 mm |
| Product Net Height | 85 mm |
| Product Net Depth / Length | 64 mm |
| Product Net Weight | 70 g |
| Built-In Depth (t2) | 64 mm |
| Package Level 1 Units | box 6 piece |
| Package Level 1 Width | 105 mm |
| Package Level 1 Height | 85 mm |
| Package Level 1 Depth / Length | 64 mm |
| Package Level 1 Gross Weight | 0.423 kg |
| Package Level 1 EAN | 8012542009634 |
| Package Level 2 Units | box 180 piece |
| Package Level 2 Width | 105 mm |
| Package Level 2 Height | 85 mm |
| Package Level 2 Depth / Length | 64 mm |
| Package Level 2 Gross Weight | 423 g |
| Package Level 2 EAN | 8012542637523 |
| Package Level 3 Units | 180 piece |
| Package Level 3 EAN | 8012542009641 |
| Minimum Order Quantity | 1 piece |
| BV Certificate | 9AKK108467A0330 |
| CCC Certificate | 9AKK108467A0341 |
| Declaration of Conformity - CE | 2CSC444001D2701 |
| IMQ Certificate | 9AKK108467A0322 |
| Instructions and Manuals | No document needed |
| Data Sheet, Technical Information | 2CSC444002B0204 |
| Certification Agency | IMQ, BV, CCC, EAC |
For complete electrical ratings, applicable standards, connection requirements and installation instructions, consult the official ABB reference ↗.
